AllRoad E16

$69,500.00

Brand

Sleeps

4

Year

2023

Condition

New

What

Listed: October 5, 2023

The legendary AllRoad E16 offroad caravan for sale. New. Excess to needs. Incredible features, finish and value for money.  All you could desire for exploring remote areas, or hitting the well trodden routes in complete comfort .





Overall Size:


6020(L)*2250(W)*2 718(H)/MM


Inner Body size


5104(L)*2050(W)*2 000(H)/MM


Berth


2-4


Tare Mass


2350kg


tow ball weight


210kg


ATM


2850kg


Chassis:


One-piece welded and fully hot dipped galvanized chassis with tar pain protection. .


Drawbar(A Frame):


3 MM Thick Q345 steel square tube A-frame.


Hitch:


AU standard pin  off-road hitch


Plug:


50 amp Anderson plug.(Charge the battery,Global unified standard adaptation)


Au 7-Pin plug) incorporating brake controller


Body


Aluminium  Alloy  Frame combining Two-layer truck and aluminium caravan. panel with Insulation sandwich.





Brakes


Electric brake


hand brake





Suspension


Heavy duty 2* independent suspension with dual shock absorbers/heavy duty springs


Stabiliser legs


4*drop down heavy duty fully adjustable stabiliser legs.


Wheels &Tyres


2 * Off-road 265/75 R16 tyres with 6 stud aluminium alloy rim with  2 spare tyres and rims .





Entrance door


one with mosquito screen and one with window dust Proof cover to ventilation.





Steps


Manual extend-retract step





Interior


Bathroom and spectate shower


Hot and Cold water Shower & Tap


Thetford toilet (C-402 Model)


Exhaust  dual Action fan with light on roof to both shower and bathroom areas


Bathroom Black Sink, black mixer tap, with benchtop and storage


Separate shower area with sliding door, black handrail shower, towel hooks, shower shelves .





Sleeping area


main bed +sofa / dining table





Cabinet


plywood or aluminium side cabinet and cooktop cabinet. All soft close and lockable for travelling





Floor


Polythene wood floor





Kitchen System


External slide our kitchen with AGA stoves, sink and shelf


Interior countertop


Interior Thetford Cooktop/oven (T, S/S sink and hot and cold water .





Water System


Fresh – 120L+ 80L Special light plastic water tank,The outside is protected by checker plate.


Grey Water Water – 80L Special light plastic waste water tank,The outside is protected by checker plate


External shower


External tap to draw bar





Water heater


Truma gas-electric hot water heater (14L)





Water pump


Use standard 12V diaphram pump.





Electric System


DC charger – 30Amp DC charger.(Charge the battery)


Inverter – 2000W(12V DC Convert to 230V Or 110V)


Main Switch panel


outdoor waterproof plug and waterproof socket.Can plug into a generator or shore power.


Reversing camera and portable display


Brake controller





Lighting


Fully submersible external  LED lights.


Internal Led ceiling lights


Reading lighting, touch sensitive to mood


Lighting


Large front spot light


LED wall external Lights


2 x internal fans





Battery


2*100AH Power deep cycle batteries





Solar panel


Roof 12V 200W Monocrystalline silicon flexible roof solar panels.





TV System


17 Inch LCD TV with DVD player+cd radio,And 2 internal and 2 external Speakers .





Air conditioner


Dometic roof  reverse cycle air conditioner/heater





Diesel Heater


LF Bros w55  dorsal air heater with 2 vents





Refrigerators


Internal dometic brand 80L


Allowance for external fridge/freezer in slide out draw





Other Features


Rear Jerry Can Holder and 2 front Gas Bottle holders. stone guard


External Shower & PVC Room Awning – 4.5M*2.0M Box Style Awning.


Checker Plate – The Checker plate is at the bottom, providing slip and scratch resistance.


4.5m awning with enclosed sides


city water inlet


thermal insulating film for water tank


light weight sandwich composite panel for roof combined inverter


Fire extinguisherO


Slide out fridge draw


Slide out large storage draw.

Specs

  • VIN:
    6U9VSS00000296859
  • Chassis Number:
    n/a
  • Condition:
    New
  • Warranty:
    Yes
  • Sleeps:
    4
  • External cabin length:
    6020
  • Empty Ball Mass:
    n/a
  • Tare Mass:
    n/a
  • GTM:
    n/a
  • ATM: :
    n/a

Gallery

Where

Belmont, Victoria, Australia
