AllRoad E16

The legendary AllRoad E16 offroad caravan for sale. New. Excess to needs. Incredible features, finish and value for money.  All you could desire for exploring remote areas, or hitting the well trodden routes in complete comfort .



Overall Size:

6020(L)*2250(W)*2 718(H)/MM

Inner Body size

5104(L)*2050(W)*2 000(H)/MM

Berth

2-4

Tare Mass

2350kg

tow ball weight

210kg

ATM

2850kg

Chassis:

One-piece welded and fully hot dipped galvanized chassis with tar pain protection. .

Drawbar(A Frame):

3 MM Thick Q345 steel square tube A-frame.

Hitch:

AU standard pin  off-road hitch

Plug:

50 amp Anderson plug.(Charge the battery,Global unified standard adaptation)

Au 7-Pin plug) incorporating brake controller

Body

Aluminium  Alloy  Frame combining Two-layer truck and aluminium caravan. panel with Insulation sandwich.



Brakes

Electric brake

hand brake



Suspension

Heavy duty 2* independent suspension with dual shock absorbers/heavy duty springs

Stabiliser legs

4*drop down heavy duty fully adjustable stabiliser legs.

Wheels &Tyres

2 * Off-road 265/75 R16 tyres with 6 stud aluminium alloy rim with  2 spare tyres and rims .



Entrance door

one with mosquito screen and one with window dust Proof cover to ventilation.



Steps

Manual extend-retract step



Interior

Bathroom and spectate shower

Hot and Cold water Shower & Tap

Thetford toilet (C-402 Model)

Exhaust  dual Action fan with light on roof to both shower and bathroom areas

Bathroom Black Sink, black mixer tap, with benchtop and storage

Separate shower area with sliding door, black handrail shower, towel hooks, shower shelves .



Sleeping area

main bed +sofa / dining table



Cabinet

plywood or aluminium side cabinet and cooktop cabinet. All soft close and lockable for travelling



Floor

Polythene wood floor



Kitchen System

External slide our kitchen with AGA stoves, sink and shelf

Interior countertop

Interior Thetford Cooktop/oven (T, S/S sink and hot and cold water .



Water System

Fresh – 120L+ 80L Special light plastic water tank,The outside is protected by checker plate.

Grey Water Water – 80L Special light plastic waste water tank,The outside is protected by checker plate

External shower

External tap to draw bar



Water heater

Truma gas-electric hot water heater (14L)



Water pump

Use standard 12V diaphram pump.



Electric System

DC charger – 30Amp DC charger.(Charge the battery)

Inverter – 2000W(12V DC Convert to 230V Or 110V)

Main Switch panel

outdoor waterproof plug and waterproof socket.Can plug into a generator or shore power.

Reversing camera and portable display

Brake controller



Lighting

Fully submersible external  LED lights.

Internal Led ceiling lights

Reading lighting, touch sensitive to mood

Lighting

Large front spot light

LED wall external Lights

2 x internal fans



Battery

2*100AH Power deep cycle batteries



Solar panel

Roof 12V 200W Monocrystalline silicon flexible roof solar panels.



TV System

17 Inch LCD TV with DVD player+cd radio,And 2 internal and 2 external Speakers .



Air conditioner

Dometic roof  reverse cycle air conditioner/heater



Diesel Heater

LF Bros w55  dorsal air heater with 2 vents



Refrigerators

Internal dometic brand 80L

Allowance for external fridge/freezer in slide out draw



Other Features

Rear Jerry Can Holder and 2 front Gas Bottle holders. stone guard

External Shower & PVC Room Awning – 4.5M*2.0M Box Style Awning.

Checker Plate – The Checker plate is at the bottom, providing slip and scratch resistance.

4.5m awning with enclosed sides

city water inlet

thermal insulating film for water tank

light weight sandwich composite panel for roof combined inverter

Fire extinguisherO

Slide out fridge draw

Slide out large storage draw.
